Botgrinder Demibot Frame Kit - DIY Robot Building Kit for STEM Education & Robotics Enthusiasts | Perfect for School Projects, Competitions & Hobbyists

Save 45%

Botgrinder Demibot Frame Kit - DIY Robot Building Kit for STEM Education & Robotics Enthusiasts | Perfect for School Projects, Competitions & Hobbyists

Sku: 25953013 in stock

$49.49

$89.99

45% Off

Delivery & Return: Free shipping on all orders over $50

Estimated Delivery: 10-15 days international

22 people viewing this product right now!

Guranteed safe checkout

Description

The Demibot Frame is here!!! "When Botgrinder and the Ummagawd Company get together, magic happens."

We've made a frame that can not only survive the most brutal bando gauntlet imaginable but can also deliver the smoothest freestyle flow you can ever experience.

The same details that make this frame nearly indestructible also make it one of the smoothest flying frames available. With 6mm thick arms held together by 3mm thick plates and 6mm OD standoffs, this frame bolts solidly together into one sturdy mass, which makes gyros very happy.

The great durability, flight performance, and sick looks of the DemiBot can be attributed to a few things working very well together. The beefy 6mm arms, mated together with a 6mm thick central block, all held together with 3mm thick plates, make the core of this frame a significantly dense mass. The Demibot is definitely no ultralight, but that's also why it takes a beating and flies just so damn smoothly.

Check out our other , as well as the rest of our selection!

Features

The block facilitates an interface in which all 4 arms meet in the middle. This makes the entire assembly act like one solid piece but with just the right amount of energy loss (aka resonance damping).
If you can manage to break an arm, it can be replaced by removing just ONE bolt. This is achieved by having each arm wedged between the adjacent arm and the center block. Therefore it only needs one bolt to keep it there.
With some clever design tricks, this true-X frame maintains hardware independence between the flight stack and the arms while keeping the electronics in the center. We’ve included press nuts for the flight stack, as well as an installation tool (M3 screw and washer) so that you easily seat it yourself. You just choose which mounting configuration fits your electronics and press in the nuts.

Specifications

Stack Mounting: Two 30.5x30.5mm stacks(center and rear) + Two 20x20mm stacks
FPV Camera Mount: 20mm(DJI) or 19mm Micro cam
Motor Mount Pattern: 16x16
Main Plate Thickness: 3mm
Frame Shape: X
Frame Weight: 165 grams
Arm Thickness: 6mm

Includes

1x Top Plate
2x Arms
1x Bottom Plate
1x Mid Plate (with a bag of press nuts)
1x Hardware Kit
1x Ummagrip Battery Pad
2x Kevlar Battery Straps
1x TPU FPV Camera Mounts
